Window Equipment Aluminum cnc double mitre saw for window making machines

Equipment features:

☆ Mainly used for industrial aluminum profiles, doors and Windows, curtain wall materials cutting, can also be used for PVC and wood

Cutting and laying of profiles.

☆ The machine adopts CNC technology, and can complete the automatic positioning cutting and material cutting of different specifications and sizes of profiles.

☆ Select high quality aluminum special hard alloy saw blade, outer diameter up to 550, high line speed, high processing accuracy.

☆ CNC transmission adopts high standard gear rack, transmission precision is high, positioning accuracy, smooth work.

☆ High precision spindle makes the saw blade rotate stably and effectively improves the surface quality of the workpiece.

☆ The gas-liquid damping cylinder can realize uniform feed speed regulation and smooth movement.

☆ Use a micro spray cooling device.

☆ Automatic head rotation, two-way positioning, clamping, can work independently of a single head. Automatic opening and closing of the protective cover,

Make the operation safer.

☆ The saw blade is automatically arranged at 45° and 90°135° angles, and the protective cover is automatically opened and closed to make the operation safer.

☆ The saw blade is from back to front, the saw cutting profile is more safe and reliable, and the saw cutting height and saw cutting width are large.

☆ The absolute value servo upgrade memory function is available without return reference when starting up.

☆ Built-in printer function, support for USB drive data import function.
