Feature
1. used for milling all styles of water slots and air strain stability grooves,
2. clamping one time to complete axis water slot processing
3. with 2 milling heads to fulfill the unique requirements of the processing profile.
4. the period of milling water slot within 60mm is adjustable and its usage range is huge.
5. impartial feeding device and best milling quality.
Specification
|
Power supply |
220V 50HZ or customer specification. |
|
Input power |
0.38*3 KW |
|
Motor rotary speed |
25000r /min |
|
Operation air pressure |
0.5-0.8MPa |
|
Milling cutter diameter |
Φ5, Φ4 |
|
Slot Depth |
30m |
|
Slot Length |
30-60mm |
|
Overall dimension |
1955x750x1600mm |
|
Weight |
300kg |
Standard accessory
|
Solenoid Valve |
Airtac |
|
Cylinder |
Airtac |
|
Motor |
Anhui Sanyang |
|
Air Filter Device |
STNC |
|
Electrical |
Schneider and CHINT |
|
AC Contactor and Circuit Breaker |
CHINT |
