Feature
1. used for 45 ° glass glazing bead lowering and the mindset milling and decreasing.
2. one time ought to slicing quantities of glass glazing bead.
3. with diploma rulers, it is able to processing the glazing bead in step with the favored period a good way to make sure the precision of the processing period and eliminate the fan body meeting mistakes.
4. four portions noticed blade make certain specific lowering, double decreasing one every surrender to mill the hook foot.
5. Vertical clamping device and special designed cutting jig ensure stable positioning.
6. Furthermore, there is a tiny adjusting device, with which you can adjust the tihgtnesss degree after installing the glazing bead according to need.

|
Parameter |
|
|
Air Pressure |
0.4~0.7MPa |
|
Air consumption |
80L/min |
|
Input Voltage |
380V 50~60Hz or As Customer need |
|
Input Power |
2*0. 75Kw |
|
Cutting range |
320-1800mm |
|
Cutting Width |
120mm |
|
Cutting profile height |
29mm |
|
Overall size |
1900*700*1350 mm |
|
Weight |
300kg |
