Feature
1. used for 45 ° glass glazing bead reducing and the attitude milling and decreasing.
2. one time could slicing portions of glass glazing bead.
3. with degree rulers, it could processing the glazing bead in keeping with the desired length with a purpose to ensure the precision of the processing length and remove the fan frame assembly mistakes.
4. four portions noticed blade make certain specific lowering, double decreasing one every surrender to mill the hook foot.
5. Vertical clamping device and special designed cutting jig ensure stable positioning.
6. Furthermore, there is a tiny adjusting device, with which you can adjust the tihgtnesss degree after installing the glazing bead according to need.
|
Parameter |
|
|
Air Pressure |
0.4~0.7MPa |
|
Air consumption |
80L/min |
|
Input Voltage |
380V 50~60Hz or As Customer need |
|
Input Power |
2*0. 75Kw |
|
Cutting range |
320-1800mm |
|
Cutting Width |
120mm |
|
Cutting profile height |
29mm |
|
Overall size |
1900*700*1350 mm |
|
Weight |
300kg |
