1).This machine, it is our common welding machine, if your profile is Europe profile, it is no problem, if your profile is America type profile,it needs to make backup moulds according to the profile sample, so if it is America type profile, it needs customer post the profile sample to us,then we make the moulds according to the sample.
2).If you profile thickness(height) is higher than 120mm, and also want to use this common welding machine, we can make the welding head higher with some device,but it needs to customer pay some extra charge about this.
3).The machine is used for welding and the combination,used for PVC/UPVC/Plastic/Vinyl profile welding for making window door.with programming control and pneumatic driving systems, it has the features of high reliability, large processing range and easy operation, the two heads can work individually, simultaneously and combative.
4).This machine can weld one window per 5 minutes.
|
Brand |
SETH |
|
Weight |
950kg |
|
Dimension |
4500*1000*1700mm |
|
Welding length |
400~3500mm |
|
Air Consumption |
100L/min |
|
Welding profile height |
20~110mm |
|
Input power |
2.5kw |
|
Operation air pressure |
0.4 ~ 0.6Mpa |
