Single Head Corner Crimping Machine for Aluminum Profile Win-door

Equipment Features:
code type is suitable for aluminum door and window curtain corner rivet connection.
by process control, hydraulic system to provide large riveting of angular momentum, strong power, high speed, stable work.
group wide Angle of knife up and down adjustment, easy adjustment, to adapt to the high Angle, thicker profile of the group.
before positioning with elevating, convenient take put materials.
configurable two point knife, knife ladder, make the group Angle of higher intensity.

Category :
Corner Crimping Machine
Browse number : ...
Release time : 2026-06-11

Consult now

Detailed Description

Power supply	380V 50Hz
Total motor power	3.0Kw
Rated pressure	20MPa
Operating pressure	0.6~0.8MPa
Air consumption	5L/min
Front positioning stroke	170mm
Backward cutter stroke	120mm
Adjustment range of front positioning	140mm
Adjustment range of angle cutter	160mm
Height of machined profile	160mm
Fuel tank capacity	40L
Oil pump size	10 “
Overall dimension	870×1200×1100mm
Weight	700kg
