With high automation, the advance and retreat of clamping and sawing are controlled by pneumatic system, which is convenient to operate, safe and reliable, and has high productivity. With automatic counting function. Continuous cutting of 6-meter angle profile can be realized only by clamping once.
Automatically save the number of cut segments in case of power failure.
Adopt micro spray cooling device to save the processing cost of doors and windows (alternative).
|
Power supply |
380V/50Hz |
|
Power supply |
1.5kW |
|
Motor speed |
2800r/min |
|
Working pressure |
0.6~0.8MPa |
|
Auto feeding length |
2~180mm |
|
Cutting width |
Max. 120mm |
|
Cutting height |
Max. 220mm |
|
Cutting length |
|
|
Cutting angle |
90° |
|
Feeding speed |
0~3m/min |
|
Saw blade specification |
Ф450×3.8×Ф30 Z=120 |
|
Overall dimension |
5670×1770×1840mm |
|
weight |
450kgs |
