● Simple operation and easy to use, to solve the factory recruitment difficulties, label printing function, error prevention function, profile error beyond the range of no cutting.
● High precision, integrated casting table, integrated spindle direct motor, integrated gas-liquid damping cylinder, T1, T2 heads are located on the integrated guide rail.
● Support a variety of data import methods: Internet, LAN, U disk, manual input, etc. It can realize the data docking of common optimization software in the market, such as Xinger, Changfeng and Chuangying
● Environmental protection function, unique dust removal, vacuuming design, vacuuming rate of 70%, clean site, reduce cleaning frequency, improve work efficiency.
● It is equipped with patented rotary lifting bracket to avoid cutting errors caused by sagging in the middle. It is equipped with movable profile bracket.
● The latest arc cutting technology, sawing profile is safer, faster and more reliable
|
Power source |
380V 50HZ |
|
Saw head motor |
2× 3KW/3000r/min |
|
Working pressure |
60L/min
|
|
Air consumption |
0.6 ~ 0.8MPa
|
|
Sawing length
|
Max5000mm min 280mm(the shortest cutting function of short material is 200mm)
|
|
Cutting width |
max 150mm |
|
Maximum cutting surface |
45°150×170mm 90°150×345mm
|
|
The most generous pipe cutting |
150×200mm |
|
Sawing Angle: |
45° -90 ° |
|
Feed speed |
stepless speed regulation 0-4m/min
|
|
Saw blade specification |
ø500 × ø30 × 4.4× Z120
|
|
Overall size |
6550× 1300× 1800 mm |
|
Weight |
2000kg |
|
Precision of repeated fixed length |
≤ 0.02mm
|
|
Profile cutting Angle tolerance |
± 3 ' |
|
Flatness of cutting surface |
≤ 0.02m |
|
Cutting surface roughness
|
Ra12.5μm |
